El R5010 es el nuevo enrutador de Robustel, capaz de 5G y que admite bandas globales de 5G, 4G y 3G. El R5010 aprovecha nuestro probado y comprobado sistema operativo de alto rendimiento, RobustOS 5, desarrollado internamente por Robustel y que ha superado exhaustivas pruebas de penetración realizadas por terceros.
El R5010 es el nuevo enrutador 5G de Robustel, que admite bandas globales de 5G, 4G y 3G. El R5010 se beneficia de nuestro probado y altamente eficaz RobustOS 5, un sistema operativo desarrollado internamente por Robustel, que ha superado rigurosas pruebas de penetración por parte de terceros.
El R5010 es compatible con la Release 16 de 3GPP y está orientado a las siguientes aplicaciones:
Banda Ancha Primaria – Los operadores de redes celulares ahora pueden ofrecer tarifas ilimitadas de 5G a precios muy razonables. Para muchos, la oportunidad de prescindir de los cables y utilizar una conexión a Internet inalámbrica puede ser favorable tanto técnica como comercialmente.
SD-WAN – Aunque muchos dispositivos cuentan con opciones de conectividad celular integradas, el R5010 puede proporcionar una forma de bajo costo para añadir una ruta de respaldo 5G y, debido a su capacidad de ubicarse externamente al dispositivo, tiene mayores probabilidades de captar una buena señal 5G.
RCMS es el servicio gratuito de monitoreo de enrutadores de Robustel que es completamente compatible con el R5010. Se trata de un software extremadamente pulido, alojado en MS Azure y disponible como una instancia de alojamiento privado. Puedes probar la plataforma gratuita de gestión de enrutadores de Robustel registrándote aquí.: https://rcms-cloud.robustel.net
Key Features:
- Low cost industrial 5G Router
- Global 5G/4G/3G cellular connections
- Cutting-edge 5G 3GPP Release 16 cellular interface
- 1 x 1000Mbps Ethernet port
- PoE-PD, compatible with IEEE 802.at standard
- USB modem mode supported
- Fully programmable Operating System with a well-documented SDK
- Multiple VPN options available including DMVPN, IPsec, L2TP + more…
- Free cloud management platform – RCMS
- Robust metal enclosure with small footprint – DIN-rail + wall mount options
| Cellular Interface | |
| Number of antennas | 4 (ANT0 + ANT1 + ANT2 + ANT3) |
| Connector | SMA-K |
| SIM | 2 x Mini SIM (2FF) |
| Ethernet Interface | |
| Number of ports | 1 x 10/100/1000 Mbps, LAN |
| Isolation protection | 1 KV |
| LAN port | Support 802.3at PD feature on ETH |
| Others | |
| Reset button | 1 x RST |
| LED indicators | 1 x RUN, 1 x Modem, 1 x USR, 1 x RSSI, |
| USB | 1 x USB 3.1 (Type C) for Power Supply, Network Supply and Debug |
| Watchdog | External |
| Software (Basic features of RobustOS) | |
| Network protocols | PPP, PPPoE, TCP, UDP, DHCP, ICMP, NAT, HTTP, HTTPs, DNS, ARP, NTP, SMTP, Telnet, VLAN, SSH2, DDNS, etc. |
| VPN tunnel | IPsec, OpenVPN, GRE |
| Firewall | DMZ, anti-DDoS, Filtering (IP/Domain name/MAC address), Port Mapping, Access Control |
| Management | Web, CLI, SMS |
| Others | Data Guard, etc. |
| SDK | |
| Supported programming languages | C, C++ |
| Flash available for SDK | 110MB |
| RAM available for SDK | 45MB |
| App Center (Available Apps for RobustOS) | |
| Apps* | L2TP, PPTP, DMVPN, VRRP, QoS, SNMP, Language, RCMS, Data Guard |
| *Upon request. For more Apps please visit www.robustel.com. | |
| Power Supply and Consumption | |
| Connector | 4-pin Micro-Fit socket |
| Input voltage | 9 ~ 60 VDC5V/3A by USB Type C Port |
| PoE-PD Voltage | Possibility to power up through ETH 44~57 VDC |
| Power consumption | Idle: 1.5wData link: 15w |
| Physical Characteristics | |
| Ingress protection | IP30 |
| Housing & Weight | Aluminum, 276g |
| Dimension | 100*94*30 mm |
| Installations | DIN rail mounting, desktop or wall mounting |
| Operating Temperature | -40 ~ +70°C |
| Storage Temperature | -40 to +85 °C |
| Relative Humidity | 5 to 95% RH |
| Regulatory and Type Approvals | |
| Environmental | RoHS2.0 |
| Physical Features | IEC 60068-2-6 (Sinusoidal Vibration)IEC 60068-2-64 (Random Vibration)IEC 60068-2-27 (Mechanical Shock) |
| EMI | EN 55032 Conducted Emission Class BEN 55032 Radiated Emission Class B |
| EMS | EN 61000-3-2 (Harmonic Current) |
| EN 61000-3-3 (Voltage Flicker)EN 61000-4-2 (ESD) Contact Level 3, Air Level 3EN 61000-4-3 (RS) Level 2EN 61000-4-4 (EFT) Power Ports Level 2EN 61000-4-4 (EFT) Signal Ports Level 2EN 61000-4-5 (Surge)Line to line Level 2, Line to ground Level2EN 61000-4-6 (CS) Level 2EN 61000-4-11 (Dips) Class 2 | |
| Others | |
| Reset button | 1 x RST |
| LED indicators | 1 x RUN, 1 x Modem, 1 x USR, 1 x RSSI, 1 x Wi-Fi 2.4G，1 x Wi-Fi 5G |
| Built-in | Watchdog |
| Software (Basic features of RobustOS) | |
| Network protocols | PPP, PPPoE, TCP, UDP, DHCP, ICMP, NAT, HTTP, HTTPs, DNS, ARP, NTP, SMTP, Telnet, VLAN,SSH2, DDNS, etc. |
| VPN tunnel | IPsec, OpenVPN, GRE |
| Firewall | DMZ, anti-DoS, Filtering (IP/Domain name/MAC address), Port Mapping, Access Control |
| Management | Web, CLI, SMS |
| Serial port | Transparent, TCP Client/Server, UDP, Modbus RTU to TCP |
| Others | Data Guard, etc. |
| SDK | |
| Supported programming languages | C, C++ |
| Flash available for SDK | 5MB |
| RAM available for SDK | 128MB |
| App Center (Available Apps for RobustOS) | |
| Apps* | L2TP, PPTP, DMVPN, VRRP, QoS, SNMP, Language, RCMS, Dynamic Route,Data Guard, Captive Portal, WLAN Multi AP |
| *Upon request.For more Apps please visit www.robustel.com. | |
| Power Supply and Consumption | |
| Connector | 2-pin 3.5 mm female socket with lock |
| Input voltage | 12 ~ 36 VDC |
| Power consumption | Idle: 370 mA@12 VData link: 1.7 A (peak) @12 V |
| Physical Characteristics | |
| Ingress protection | IP30 |
| Housing & Weight | Aluminum, 475 g |
| Dimension | 136 x 115 x 32 mm |
| Installations | DIN rail mounting, desktop or wall mounting |
| Operating Temperature | -20 ~ +55°C (Normal temperature)-25 ~ +70°C (Extended temperature) |
| Storage Temperature | -40 to +85 °C |
| Relative Humidity | 5 to 95% RH |
| Regulatory and Type Approvals | |
| Environmental | RoHS2.0 |
| Physical Features | IEC 60068-2-6 (Sinusoidal Vibration)IEC 60068-2-64 (Random Vibration)IEC 60068-2-27 (Mechanical Shock) |
| EMI | EN 55032 Conducted Emission Class BEN 55032 Radiated Emission Class B |
| EMC | EN 61000-3-2 (Harmonic Current) |
| EN 61000-3-3 (Voltage Flicker)EN 61000-4-2 (ESD) Contact Level 3, Air Level 3EN 61000-4-3 (RS) Level 3EN 61000-4-4 (EFT) Power Ports Level 2Signal Ports Level 3EN 61000-4-5 (Surge)Line to line Level 2, Line to ground Level 3EN 61000-4-6 (CS) Level 3EN 61000-4-11 (Dips) Class 2 | |
| Model | PN | Frequency Bands* | Country/Region | Certification (*In Progress) |
| R5010-A-5G-A28EU | B113001 | 5G:NR SA/NSA:n1/n3/n5/n7/n8/n20/n28/n38/n40/n41/n75/n76/n77/n784G:LTE FDD: B1/B3/B5/B7/B8/B20/B28/B32LTE TDD: B38/B40/B41/B42/B433G:WCDMA: B1/B5/B8 | EMEAANZ | CE*, UKCA*, CB*, RCM* |
*For more information about frequency bands in different countries, please contact your Robustel sales representative.
